UP2500 lithium iron phosphate battery is one of the new energy storage products developed and manufactured by Pylontech. It can be used to support the reliable powering of various types of devices and systems. The UP2500 is especially suitable for high performance, limited installation space, limited load capacity, and long-life applications. The UP2500 has an integrated BMS battery management system that can manage and monitor information about the cell such as voltage, current, and temperature. In addition, BMS can balance the charging and discharging of cells to extend their service life. UP2500battery Pylontech Lithium Ion is currently being used by a lot of people in Zimbabwe


  • The whole module is non-toxic, non-polluting, and environmentally friendly.

  • The cathode material is made from LiFePO4 with safety performance and long cycle life.

  • Battery management system (BMS)has protection functions including over-discharge, overcharge, over-current, and high/low temperature.

  • The system can automatically manage the charge and discharge state and balance the current and voltage of each cell.

  • Flexible configuration, multiple battery modules can be in parallel for expanding capacity and power

  • Adopted self-cooling mode rapidly reduced system entire noise; The module has less self-discharge, up to 6 months without charging it on the shelf, no memory effect, and excellent performance of shallow charge and discharge.

  • Working temperature range is from -10 to 55, (Charging 0~55; discharging -10~55) with excellent discharge performance and cycle life.

  • Small size and light weight, the standard 19-inch embedded designed module is comfortable for installation and maintenance.


Nominal Voltage (V) 25.6
Nominal Capacity (Wh) 2480
Usable Capacity (Wh) 2550
Dimension (mm) 442*420*120
Weight (Kg) 27.5
Disharge Voltage (V) 23 – 28.8
Charge Voltage (V) 28.2 – 28.8
Charge/Disharge Current (A)
56 (Continous)
100 (Peak@15s)
Communication Port RS485, CAN
Single String Quantity (pcs) 8
Working Temparature/°C 0 – 50
Shelf Temparature/°C -20 to 60
Humidity 5% – 90%
Altitude (m) ˂2000
Design Life 15+ years (25°C/77°F)
Cycle Life >6000, 25°C
Authentication Level IEC62619/RoHS/UN38.3
