Nexus Off Grid 1kva Inverter 12v Naxvp100012
Specifications
| Model | 1kva 12v |
| Related Power | 1000VA/1000W |
| INPUT | |
| Voltage | 230VAC |
| Selectable Voltage Range | 170-280VAC (For Personal Computers) ; 90-280VAC (For Home Appliances) |
| Frequency Range | 50Hz/60Hz (Auto Sensing) |
| OUTPUT | |
| AC Voltage Regulation (Batt. Mode) | 230VAC± 5% |
| Surge Power | 2000VA |
| Efficiency (Peak) | 90% – 93% |
| Transfer Time | 10ms (For Personal Computers) ; 20ms (For Home Appliances) |
| Waveform | Pure Sine Wave |
| BATTERY | |
| Battery Voltage | 12VDC |
| Floating Charge Voltage | 13.5VDC |
| Overcharge Protection | 16VDC |
|
SOLAR CHARGER & AC CHARGER
|
|
| Solar Charge Type | PWM |
| Maximum PV Array Open Circuit Voltage | 55VDC |
| Maximum PV Array Power | 600W |
| MPP Range @ Operating Voltage | N/A |
| Maximum Solar Charge Current | 50A |
| Maximum AC Charge Current | 20A |
| Maximum Charge Current | 50A |
| PHYSICAL | |
| Dimension, D x W x H (mm) | 88 x 225 x 320 |
| Net Weight (kgs) | 4.4 |
| Communication Interface | USB/RS232 |
| ENVIRONMENT | |
| Humidity | 5% to 95% Relative Humidity (Non Condensing) |
| Operating Temperature | 10°C to 50°C |
| Storage Temperature | 15°C to 60°C |
