PYLON US2000 50AH 48V 2.4KWH LITHIUM IRON BATT

,

PYLON US2000 50AH 48V 2.4KWH LITHIUM IRON BATT

PYLON US2000 50AH 48V 2.4KWH LITHIUM IRON BATT

SKU: US2000 Categories: ,

US2000 series is an ideal solution for residential storage applications, with standard 48V/50AH specification, up to 95% usable capacity, and a 6,000 cycle-life warranty.

Features

  • It is the ideal solar battery for homes and offices.
  • This Pylontech solar battery comes with up to 7 years of warranty and we have approved installers Zimbabwe wide
  • Pylontech us2000 has a life span of over 10 years and is very suitable for small and medium energy storage

Reminders

  • If the battery is stored for a long time, it is required to charge every six months and the
  • SOC should be no less than 90%.
  • The battery needs to be recharged within 12 hours after fully discharged.
  • Do not expose the cable outside.
  • All the battery terminals must be disconnected for maintenance.
  • Please contact the supplier within 24 hours if there is something abnormal.
  • Do not use cleaning solvents to clean the battery.
  • Do not expose the battery to flammable or harsh chemicals or vapors.
  • Do not paint any part of the battery, including any internal or external
  • The battery needs to be recharged within 12 hours after fully discharged.

Specifications

BASIC PARAMETERS
MODEL US2000
Nominal Voltage (V) 48
Nominal Capacity (Wh) 2400
Usable Capacity (Wh) 2200
Dimension (mm) 442*410*89
Weight (Kg) 24
Disharge Voltage (V) 45 – 53.5
Charge Voltage (V) 52.5 – 53.5
Charge/Disharge Current (A)
25 (Recommended)
50 (Max)
100 (Peak@15s)
Communication Port RS485, CAN
Single String Quantity (pcs) 8
Working Temparature/°C 0 – 50
Shelf Temparature/°C -20 to 60
Humidity 5% – 85%
Altitude (m) ˂2000
Design Life 10+ years (25°C/77°F)
Cycle Life >6000, 25°C
Authentication Level UL/IEC62619/CE/UN38.3
